Sliding-Lift (PSH)

Sliding-Lift is a simple and cost effective parking system.It utilises electric motor to drive chains or cables to lift and slide pallets.

A 2-level system occupies 3 parking spaces to store 5 vehicles and the minimum clearance for this system is 3.6m only.

Specifications
Model
PSH Sliding Lift
Parking levels
≤ 8
Optimal parking capacity
5 vehicles/set on 2 parking levels.
Compatible vehicle dimensions (mm)
5,200*1,900*1,550/1950
Laden weight (kg)
≤ 2,500
Mechanical components
Motors and chains (cables)
Power consumption for vertical movements
2.2kW
Power consumption for transverse movements
0.2kW
Vertical movement speed
7m/min
Transverse movement speed
4m/min
Identification element
IC card / Key switch
Power Supply
3-Phase AC380V / 50Hz
